Cable Management Optional
Color Frame:

Black Pearl

Plastics:
Dark Tungsten
Transport Wheels Yes
Reversible Deck Yes
Auto Stop Step sensor detection stops a moving running belt when there is no exerciser.
Water Bottle and Accessories Holder Dual holders cradle exercisers water bottle to keep it stable. Accessory tray securely supports exercisers cell phone, keeping it front and center, along with ample room for keys, membership card, etc.
Emergency Stop Safety clip and lanyard attached to the stop switch to immediately turn off power bringing the treadmill to a stop. The lanyard and safety clip can be conveniently attached to a thoughtful tab located underneath the front handrail.
Deck and Belt Deck is a one-inch Slik-Dek bed with a thin layer of wax to assist in the break-in of the new belt / deck system. The deck is composed of 52 lb / 23.6 kg high-density fiberboard core with phenolic laminate bonded on both sides. Can be flipped to double life.
Deck and belt require no external lubrication.
Rear-deck hinges and front cushioning create a laterally stable platform, reducing shock to the user and providing firm push off.
Ground Effects® Impact Control System New and improved progressive shock absorption system that absorbs high impact movements and supports a solid and controlled push off.
Elevation System Elevation system generates up to 1000 lb / 453.6 kg of thrust and operated in compression for reliable operation.
Rollers Steel tapered rollers keep the belt centered to reduce maintenance.
Frame New frame design results in an ultra-stable console, solid feel, and quiet operation.
Motor Integrated Foot Plant Technology™ Drive controller works with a 3 HP peak duty AC induction motor for a smooth, natural feel.
3-phase, sensorless variable frequency drive technology for high reliability and accurate speed control.
Console Features
Display Type Advanced LED
Numeric Keypad Yes
Motion Controls Yes
QuickStart™ Yes
Tactile Dome Keys Yes
Console Language(s) English, Dutch, French, German, Italian, Japanese, Portuguese, Russian, Spanish
Units Selection Metric or US Standard
Maximum Pause Time (Pause) 120 seconds
Maximum Workout Time Unlimited
Electronic Readouts Speed
Incline

Distance, Pace,
Average Speed
Calories
Heart Rate
Time Elapsed,
Time Remaining

% Complete, Time in Zone, Segment Time, Cals/min, Cals/hr, watts, METS, Target HR, Average HR, Elevation Gain
Preset Programs Weight Loss
Custom Weight Loss HRC
Weight Loss HRC
1 Aerobic
2 Aerobic
Heart Rate
Basic HRC
Custom Weight Loss HRC
Weight Loss HRC
Performance
Track
5K
Gerkin Fitness Test
Variety
Random
1 Cross Country
2 Cross Country
1 Gluteal
2 Gluteal
1 Custom
2 Custom
Interval
1-1 Interval
1-2 Interval
1-3 Interval
Custom Interval
Manual
Manual
Heart Rate Monitoring
Touch Touch heart rate sensors located on fixed handlebars for increased accuracy and ease-of-use by users of all sizes.
Telemetry Equipped for heart rate
telemetry reading using a chest strap.
Integrated Entertainment Options
Mobile Device Charger Yes
Reading Rack Integrated
Personal Viewing System (PVS) Optional
Entertainment Cap / Wireless Receiver Optional
Network Capabilities
Diagnostics Ability to set club parameters, e.g. limit exercise time, set default language and pause time.
CSAFE Enabled Yes
Equipment Specifications
Roller Diameter (inches / cm) 2.5 in / 6.35 cm
Power Cord Management ICE 320-C19 inlet supporting Schuko and BSI plugs
Handrail Length (inches / cm) 18 in / 45.7 cm / 48 cm
Maximum User Weight 350 lb / 159 kg
Step-up Height 8.4 in / 21.3 cm
Speed Range 0.5 – 12 mph / 0.8-19.2 km/h
Decline / Incline Range 0% to 15% incline in 0.5% increments
Running Surface (L X W) 60 X 22 in / 153 X 56 cm
Equipment Dimensions and Weight
Height with PVS 78 in / 198 cm
Length 83 in / 211 cm
Width 35 in / 89 cm
Equipment Weight 325 lb / 147 kg
Height 62 in / 157.5 cm
Shipping Dimensions and Weight
Length 92 / 42 in / 234 / 107 cm
Width 39 / 39.5 in / 99 / 100 cm
Height 23.5 / 24 in / 60 / 61 cm
Shipping Weight (base equipment) 427 lb / 194 kg
Power Requirements
Equipment Powered
International 240 VAC IEC 320-C19 inlet supporting applicable country-specific power cord
U.S. & Canada 240 VAC Dedicated 220V- 240V/20A circuit with 6-20R NEMA receptacle
U.S. & Canada 120 VAC Dedicated 120V/20A circuit with 5-20R NEMA receptacle
Personal Viewing Screen (PVS) Powered
Cord Length 12 feet / 3.7 meters
Regulatory
UL UL 1647
FCC FCC
ETL ETL
CE CE
EN957 EN957 / ASTM
